PoE Hat за Rapberry Pi (Power Over Ethernet)

PoE HAt съвместима с MaticBox.Както се вижда на снимките, може да се изпозлва в комбинация с вентилатор.

Specification:

Compliant IEEE802.3af PoE standard

Support the IEEE 802.3af/802.3at the Power over Ethernet PoE Switch
Support 48V~57V Passive Power Over Ethernet PoE Switch
Support 48V~57V Passive Power Over Ethernet PoE injector

Support Power sourcing equipment (PSE) Power Pin:support both 1/2(+/-),3/6(-/+) or 4/5(+),7/8(-)
Isolation: 2.5kV
Power Input:  DC38~57V
Power Output: DC5V 2.5A

Operation Temperatue:-10℃ ~ 75℃
Storage Temperature:-30℃ ~ 80℃
